Cost Effective NEW 800TVL SONY CCD Effio V WDR Low Lux Video Mini Camera

FOB Reference Price:Get Latest Price
$15.00 - $20.00 / Piece | 5 Piece/Pieces (Min. Order)
Type:
Analog Camera
Style:
Mini camera
Samples:
Place Sample Order
Lead Time:
Quantity(Pieces) 1 - 100 >100
Est. Time(days) 7 Negotiable
Customization:
Customized logo (Min. Order: 100 Pieces)
Customized packaging (Min. Order: 500 Pieces)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
Censee
Model Number:
CS-NC130CSE-V
Special Features:
Low Lux Video Camera
Sensor:
CCD
Video Compression Format:
H.264
Technology:
Pinhole
item:
800TVL SONY CCD Effio V WDR Low Lux Video Camera
Image Device:
1/3" Sony super HAD CCD
Electronic Shutter:
PAL:1/50~1/100,000 Sec; NTSC:1/60~1/100,000 Sec, auto
Lens Option:
pinhole lens,board lens,wide angle lens,vari-focal lens available
Sync System:
Internal Synchronization
Supplied Accessories:
User manual,cable,screw,bracket
Keyword:
Low Lux Video Camera
Supply Ability
Supply Ability:
30000 Piece/Pieces per Month Low Lux Video Camera
Packaging & Delivery
Lead Time :
Quantity(Pieces) 1 - 100 >100
Est. Time(days) 7 To be negotiated

800TVL SONY CCD Effio V WDR Low Lux Video Camera

Low Lux Video Camera

Product Description



This SONY CCD Effio-V 800TVL Mini CCD Video Camera can be used for ATM Surveillance and FPV System. DC5-15V wide range and small size 30x30mm. With OSD and WDR functions, great BLC, you can get your excellent image.



Fetures:
* Pinhole lens, wide angle lens, vari-focal lens are available for options.

* Compact size for & wide range power supply DC 5-15V, more convenient for different applications.



* Day&Night, Color , B/W for option; or you can set time to process the picture changing from Color to B/W .



* The Shutter,Gamma, AGC,White Balance is adjustable,getting your favorite picture during the varying lighting condition .



* Nice back light compensation, used for the ATM surveillance or under sharp contrast in lighting conditions like FPV (aeria video), etc.

> 1/3" SONY double-scan CCD
> SONY Effio-V,CXD4141GG
> 800TVL Resolution
> 0.01Lux / F2.0
> AGC,Shutter,Privacy,Motion,HLC/BLC
> Day & Night
> WDR, ATR-EX2,
> E-Zoom,DIS ,3D-DNR
> Built in OSD menu
> Compact size:30x30mm



Model No.

CS-NC130CSE-V

Image Device

1/3" SONY double-scan CCD Effio-V

Scanning System

2:1 Interlace

Scanning Frequency

PAL : 15.625 KHz(H), 50Hz(V) / NTSC : 15.734 KHz(H), 59.94 Hz(V)

H. Resolution

800TVL

Effective Pixels

PAL: 976 (H) X 582(V) / NTSC: 976 (H) X 494 (V)

S/N Ratio

More than 52dB(AGC 0FF)

Min. Illumination

0.01 Lux / F2.0

Shutter

Auto,Manual,Fix

AGC

6DB~44.8DB

White Balance

ATW, PUSH/PUSH LOCK, USER1/USER2, MANUAL

WDR,ATR-EX

Normal/Light

DNR

3D-DNR

Day&night

Color, Auto, B/W

Privacy

Off, On(15 area)

Motion Detection

Off, On(4 area)

E-Zoom,DIS

Off / On(0~255)

HLC/BLC

OFF/ BLC/ HLC

Language

English, French,Russian, Spanish, Dutch,Chinese, Japan, Portuguese

Lens

3.6mm board lens(optional)

Power Comsumption

DC 5-15V

Dimensions (mm)

30x30mm





Packaging & Shipping
1.EXPRESS: around 3-7 working days to arrive
2.INTERNATIONAL AIR MAIL: around 2-4 weeks to arrive

Our Services
1. One year quality guarantee.
2. OEM service to meet all your need.
3. Popular model will be suggested,keep our customer updated for the information about the products..
4. 7*24 Technical support



NOTE: The RMA code will be given with the response email. Return shipping charges will be the buyer`s responsibility.
